Injection Drug Preparation Support System
MixingRoad

A Support System for Injection Drug Preparation that Fits Neatly into Any Preparation Work Area

Features

Supports Sterile/Generic Injectable and Anticancer Drug Preparation

MixingRoad is an injectable drug preparation support system that guides the user through a smart preparation procedure on a clean bench or in a safety cabinet. Mixing and adjusting TPN and anticancer drugs can be done accurately without relying on firsthand experience or knowledge.

Audible Navigation System

By simply reading the bar code on the mixing and dispensing procedure, an audible navigation system provides information such as the type of syringe to be used, the name of the chemical, the amount to be dissolved, and the amount to be extracted. Prevents preparation errors and reduces chemical losses. Images are always taken during preparation and evidence is stored for peace of mind.

Absolute Safety through Chemical Verification

Chemicals used in preparation are matched with GS1 data bars, preventing errors if those prepared in advance are incorrect. In addition, a remote audit function that a pharmacist in another room can connect to allows for one-person preparation (separate terminal required).

Spec

Product Name MixingRoad Injection Drug Preparation Support System
Model YS-MXRD
External Dimensions Main unit: 222mm (width)×405mm (depth)×410.5mm (height)
Monitor: 10.1-inch tablet
Weight Main unit only: Approx. 8kg
Electronic balance-equipped: 12kg
Power Supply AC100V(50/60Hz)
Power Consumption 100VA(Max.)
Functions Sterile/Generic injectable and anticancer drug preparation support
Dispensing procedure navigation: 5 modes
Remote inspection *Requires an additional terminal
